Modular coil systems

Various coil designs like the bifilar Tesla Coil, triangular and octagonal coils are an essential part for wireless energy transfer and generating scalar waves. We have developed a modular system that is easy to set up and can be connected to external frequency sources like computers, MP3 player, or frequency generator. The goal of this project is to enable users with limited or no experience in electronics, to build functional scalar or wireless energy transfer devices.

The setup in most basic terms requires just 2 devices and 2 cable sets. The integral part is the amplifier module which amplifies the signals from the frequency source. The amplified signals are then fed to the coil modules via the 4mm banana plug cables. The amplifier module received signals via the 3.5mm audio cable. You can use any device that is capable of outputting signals.  We suggest using a regular PC or laptop. To generate different frequencies at various waveforms you can use various programs. A good application that we like to use it this browser-based frequency generator. It works reliably on many browsers and requires no download.

The amplifier should be connected to the computer just like a regular speaker would be. If the amplifier is successfully receiving the signals and the coil is connected, the indicator LEDs will start blinking.

In the example above, a bifilar Tesla coil module is used. Instead of this module, other scalar wave coil modules could be used. Here is a list of the compatible coils.

Amplifier used: amplifier module for scalar wave coils
